IdeaCentre AIO 24ARR9
Model : F0HR005TID

PERFORMANCE
Processor AMD Ryzen 7 7735HS (8C / 16T, 3.2 / 4.75GHz, 4MB L2 / 16MB L3)
Graphics Integrated AMD Radeon 680M Graphics
Chipset AMD SoC Platform
Memory 2x 8GB SO-DIMM DDR5-4800
Memory Slots Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory Up to 16GB DDR5-4800
Storage 1TB SSD M.2 2280 PCIe 4.0x4 NVMe
Optane Memory None
Storage Support One drive, up to 1TB M.2 SSD
Card Reader None
Optical None
Audio Chip High Definition (HD) Audio, Realtek ALC233-CG codec
Speakers 3Wx2, HARMAN
Camera 5.0MP + IR
Microphone Dual Microphone
Power Supply 90W 89% Adapter
DESIGN
Display 23.8" FHD (1920x1080) IPS Anti-glare 250nits, 100Hz, 99% sRGB, hardware low blue light, 3-side borderless, Touch
Touchscreen 10-point Multi-touch
Keyboard Wireless EOS Keyboard, Cloud Grey, English
Mouse Wireless EOS Mouse, Cloud Grey
Expansion Slots Two M.2 slots (one for WLAN, one for SSD)
Case Color Cloud Grey
Stand AIO Stand
Wireless Charger None
Pen Pen Not Supported
Form Factor AIO (24 inches)
Dimensions (WxDxH) 540 x 192 x 431 mm (21.25 x 7.56 x 16.97 inches)
Weight Around 6.0 kg (13.23 lbs)
CONNECTIVITY
Ethernet Integrated 100/1000M
WLAN + Bluetooth Wi-Fi 6, 802.11ax 2x2 + BT5.2
WWAN Non-WWAN
Rear Ports 1x USB-A (USB 10Gbps / USB 3.2 Gen 2)
2x USB-A (Hi-Speed USB / USB 2.0)
1x HDMI-in 1.4
1x HDMI-out 2.1 TMDS
1x Ethernet (RJ-45)
1x power connector
Left Ports
1x USB-C (USB 10Gbps / USB 3.2 Gen 2), data transfer only
1x headphone / microphone combo jack (3.5mm)
SECURITY & PRIVACY
Security Chip Firmware TPM 2.0 integrated in SoC
SERVICE
Base Warranty 1-year, Courier or Carry-in
Included Upgrade 3Y Onsite - Idea AIO (ESS)
CERTIFICATIONS
Green Certifications ENERGY STAR 8.0
ErP Lot 3/7
GREENGUARD
RoHS / WEEE / REACH
Other Certifications
TÜV Rheinland Flicker Free
TÜV Rheinland Low Blue Light
TÜV Rheinland Ultra Low Noise
SOFTWARE
Operating System Windows 11 Home Single Language, English
Bundled Software Office Home & Student 2021
