Legion 5 16IRX9
Part Number : 83DG00BXID

PERFORMANCE
Processor Intel Core i7-14650HX, 16C (8P + 8E) / 24T, P-core 2.2 / 5.2GHz, E-core 1.6 / 3.7GHz, 30MB
Graphics NVIDIA GeForce RTX 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 140W
Chipset Intel HM770 Chipset
Memory 1x 16GB SO-DIMM DDR5-5600
Storage 512GB SSD M.2 2280 PCIe 4.0x4 NVMe
Storage Slot Two M.2 2280 PCIe 4.0 x4 slots
Card Reader microSD Card Reader
Audio Chip High Definition (HD) Audio, Realtek ALC3287 codec
Speakers Stereo speakers, 2W x2, optimized with Nahimic Audio
Camera FHD 1080p with E-shutter
Microphone 2x, Array
Battery Integrated 80Wh
Power Adapter 230W Slim Tip (3-pin)
Special Features AI Chip: LA1
DESIGN
Display 16" WQXGA (2560x1600) IPS 350nits Anti-glare, 100% sRGB, 165Hz, Dolby Vision, G-SYNC, Low Blue Light
Color Calibration Factory Color Calibration
Keyboard 4-Zone RGB Backlit, English
Touchpad Buttonless Mylar surface multi-touch touchpad, 75 x 120 mm (2.95 x 4.72 inches)
Case Color Luna Grey
Surface Treatment Aluminium Stamping (Anodized with Sandblasting)
Case Material Aluminium (Top), PC-ABS (Bottom)
Dimensions (WxDxH) 359.7 x 262.3 x 19.7-25.2 mm (14.16 x 10.33 x 0.78-0.99 inches)
Weight Around 2.3 kg (5.07 lbs)
SOFTWARE
Operating System Windows 11 Home Single Language, English
Bundled Software Office Home & Student 2021
CONNECTIVITY
Ethernet 100/1000M (RJ-45)
WLAN + Bluetooth Wi-Fi 6E, 11ax 2x2 + BT5.2
Standard Ports:
2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
1x USB-C (USB 10Gbps / USB 3.2 Gen 2), with PD 140W and DisplayPort 1.4
1x USB-C (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort 1.4
1x HDMI 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Card reader
1x Power connector
Security Chip Firmware TPM 2.0 Enabled
Other Security E-shutter
SERVICE
Warranty 3Y ADP, 3Y Legion Ultimate Support
