Legion 5 15IRX9
Model : 83JJ0016ID

PERFORMANCE
Processor Intel Core i7-13650HX, 14C (6P + 8E) / 20T, P-core 2.6 / 4.9GHz, E-core 1.9 / 3.6GHz, 24MB
AI PC Category AI-Powered Gaming PC
Graphics NVIDIA GeForce RTX 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 140W, 233 AI TOPS
Chipset Intel HM770 Chipset
Memory 2x 12GB SO-DIMM DDR5-4800
Memory Slots Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory Up to 24GB DDR5-4800 offering
Storage 512GB SSD M.2 2242 PCIe 4.0x4 NVMe
Storage Support "Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB each"
Storage Slot Two M.2 2280 PCIe 4.0 x4 slots
Card Reader None
Optical None
Audio Chip High Definition (HD) Audio, Realtek ALC3287 codec
Speakers Stereo speakers, 2W x2, optimized with Nahimic Audio
Camera HD 720p with E-shutter
Microphone 2x, Array
Battery 60Wh
Power Adapter 230W Slim Tip (3-pin)
DESIGN
Display 15.6" FHD (1920x1080) IPS 300nits Anti-glare, 100% sRGB, 144Hz, G-SYNC
Touchscreen None
Color Calibration None
Keyboard White Backlit, English
Touchpad Buttonless Mylar surface multi-touch touchpad, 75 x 120 mm (2.95 x 4.72 inches)
Case Color Storm Grey
Surface Treatment Anodizing
Case Material Aluminium (Top), PC-ABS (Bottom)
Pen Pen Not Supported
Dimensions (WxDxH) 358.8 x 261.4 x 20.5-24.65 mm (14.13 x 10.29 x 0.81-0.97 inches)
Weight Starting at 2.32 kg (5.12 lbs)
SOFTWARE
Operating System Windows 11 Home Single Language, English
Bundled Software Microsoft 365 Basic + Office Home 2024
CONNECTIVITY
WLAN + Bluetooth Wi-Fi 6, 802.11ax 2x2 + BT5.2
WWAN Non-WWAN
Ethernet 100/1000M (RJ-45)
Standard Ports "2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
1x USB-C (USB 10Gbps / USB 3.2 Gen 2), with Lenovo PD 140W and DisplayPort 1.4
1x USB-C (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort 1.4
1x HDMI 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Power connector"
Docking "Various docking solutions supported via USB-C.
SECURITY & PRIVACY
Security Chip Firmware TPM 2.0 Enabled
Fingerprint Reader None
Other Security E-shutter
MANAGEABILITY
SERVICE
Base Warranty 1-year, Courier or Carry-in
Included Upgrade 3Y ADP -IPMAIN(ESS), 3Y Legion Ultimate Support -IPMAIN (ESS)
ACCESSORIES
Bundled Accessories None
CERTIFICATIONS
Green Certifications RoHS compliant
