LOQ 15IRX9
Part Number : 83DV00A8ID

PERFORMANCE
Processor Intel Core i5-13450HX, 10C (6P + 4E) / 16T, P-core 2.4 / 4.6GHz, E-core 1.8 / 3.4GHz, 20MB
Graphics NVIDIA GeForce RTX 3050 6GB GDDR6, Boost Clock 1732MHz, TGP 95W
Chipset Intel HM770 Chipset
Memory 1x 12GB SO-DIMM DDR5-4800
Memory Slots Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory Up to 32GB DDR5-4800
Storage 512GB SSD M.2 2242 PCIe 4.0x4 NVMe
Storage Support:
Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB
Storage Slot Two M.2 2280 PCIe 4.0 x4 slots
Audio Chip High Definition (HD) Audio, Realtek ALC3287 codec
Speakers Stereo speakers, 2W x2, optimized with Nahimic Audio
Camera HD 720p with E-shutter
Microphone 2x, Array
Battery Integrated 60Wh
Power Adapter 170W Slim Tip (3-pin)
Special Features AI Chip: LA1
DESIGN
Display 15.6" FHD (1920x1080) IPS 300nits Anti-glare, 100% sRGB, 144Hz, G-SYNC
Keyboard 4-Zone RGB Backlit, English
Touchpad Buttonless Mylar surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Case Color Luna Grey
Surface Treatment Painting
Case Material PC-ABS (Top), PC-ABS (Bottom)
Dimensions (WxDxH) 359.86 x 258.7 x 21.9-23.9 mm (14.17 x 10.19 x 0.86-0.94 inches)
Weight Starting at 2.38 kg (5.25 lbs)
SOFTWARE
Operating System Windows 11 Home Single Language, English
Bundled Software Office Home & Student 2021
CONNECTIVITY
Ethernet Integrated 100/1000M
WLAN + Bluetooth Wi-Fi 6, 11ax 2x2 + BT5.2
Standard Ports:
3x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-C (USB 10Gbps / USB 3.2 Gen 2), with PD 140W and DisplayPort 1.4
1x HDMI 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Power connector
Security Chip Firmware TPM 2.0 Enabled
Other Security E-shutter
SERVICE
Warranty 2Y ADP, 2Y Premium Care
CERTIFICATIONS
Green Certifications:
ErP Lot 3
RoHS compliant
Other Certifications TÜV Rheinland Low Blue Light (Software Solution)
