LOQ 15IRX9
Part Number : 83DV00AGID
PERFORMANCE
Processor Intel Core i7-13650HX, 14C (6P + 8E) / 20T, P-core 2.6 / 4.9GHz, E-core 1.9 / 3.6GHz, 24MB
Graphics NVIDIA GeForce RTX 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 115W
Chipset Intel HM770 Chipset
Memory 1x 12GB SO-DIMM DDR5-4800
Memory Slots Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory Up to 32GB DDR5-4800
Storage 512GB SSD M.2 2242 PCIe 4.0x4 NVMe
Storage Support Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB
Audio Chip High Definition (HD) Audio, Realtek ALC3287 codec
Speakers Stereo speakers, 2W x2, optimized with Nahimic Audio
Camera HD 720p with E-shutter
Microphone 2x, Array
Battery Integrated 60Wh
Power Adapter 230W Slim Tip (3-pin)
Special Features AI Chip: LA1
DESIGN
Display 15.6" FHD (1920x1080) IPS 300nits Anti-glare, 100% sRGB, 144Hz, G-SYNC
Keyboard 4-Zone RGB Backlit, English
Touchpad Buttonless Mylar surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Case Color Luna Grey
Surface Treatment Painting
Case Material PC-ABS (Top), PC-ABS (Bottom)
Dimensions (WxDxH) 359.86 x 258.7 x 21.9-23.9 mm (14.17 x 10.19 x 0.86-0.94 inches)
Weight Starting at 2.38 kg (5.25 lbs)
SOFTWARE
Operating System Windows 11 Home Single Language, English
Bundled Software Office Home & Student 2021
CONNECTIVITY
Ethernet Integrated 100/1000M
WLAN + Bluetooth Wi-Fi 6, 11ax 2x2 + BT5.2
Standard Ports:
3x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-C (USB 10Gbps / USB 3.2 Gen 2), with PD 140W and DisplayPort 1.4
1x HDMI 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Power connector
Security Chip Firmware TPM 2.0 Enabled
Other Security E-shutter
SERVICE
Warranty 2Y ADP, 2Y Premium Care
CERTIFICATIONS
Green Certifications:
ErP Lot 3
RoHS compliant
Other Certifications TÜV Rheinland Low Blue Light (Software Solution)
